Specially designed to provide a strong grip both in the contracting (gripping round or square spigots) and in the expanding mode with up to 10″ long work piece.
- Ideal for long, unsupported hollow boxes and vases. Their serrated tooth form makes for a very powerful grip that just won’t let go.
- 35mm (1.375″) Nova Spigot Jaw set can handle spigots up to 50mm (2”) and minimum down to 30mm (13/36”).
Jaw Travel Range Table (SHOWS RANGES FOR BOTH 35 AND 45MM VERSIONS)
Imperial (Inch)
| Jaw Set & Chuck Suitability | Expanding Action Specifications | Contracting Action Specifications | |||||
| Jaw Set | Suitable Chuck | Square Stock | Spigot Mode | ||||
| Min | Max | Min | Max | Min | Max | ||
| 35mm SPIGOT JAW | Precision Midi* | 2.047 | 2.402 | 0.984 | 1.378 | 1.220 | 1.575 |
| Nova G3 | 2.047 | 2.835 | 0.984 | 1.772 | 1.220 | 1.969 | |
| SuperNova2 | 2.047 | 2.835 | 0.984 | 1.772 | 1.220 | 1.969 | |
| Titan | 2.047 | 3.268 | 0.984 | 2.165 | 1.220 | 2.362 | |
| 45mm SPIGOT JAW | Precision Midi* | 2.047 | 2.402 | 1.220 | 1.575 | 1.614 | 1.969 |
| Nova G3 | 2.047 | 2.835 | 1.220 | 2.008 | 1.614 | 2.402 | |
| SuperNova2 | 2.047 | 2.835 | 1.220 | 2.008 | 1.614 | 2.402 | |
| Titan | 2.047 | 3.228 | 1.220 | 2.402 | 1.614 | 2.795 | |
Metric (mm)
| Jaw Set & Chuck Suitability | Expanding Action Specifications | Contracting Action Specifications | |||||
| Jaw Set | Suitable Chuck | Square Stock | Spigot Mode | ||||
| Min | Max | Min | Max | Min | Max | ||
| 35mm SPIGOT JAW | Precision Midi* | 52 | 61 | 25 | 35 | 31 | 40 |
| Nova G3 | 52 | 72 | 25 | 45 | 31 | 50 | |
| SuperNova2 | 52 | 72 | 25 | 45 | 31 | 50 | |
| Titan | 52 | 83 | 25 | 55 | 31 | 60 | |
| 45mm SPIGOT JAW | Precision Midi* | 52 | 61 | 31 | 40 | 41 | 50 |
| Nova G3 | 52 | 72 | 31 | 51 | 41 | 61 | |
| SuperNova2 | 52 | 72 | 31 | 51 | 41 | 61 | |
| Titan | 52 | 82 | 31 | 61 | 41 | 71 | |
Please note, Tolerance of +/-1mm on all measurements
* Measurements with stop-screw
** Recommended with Caution
